1.螺旋風管的安裝大大減少了管道之間的連接點，減少了管件連接處的泄漏。典型的螺旋風管長度為3 ~ 6m，而典型的矩形風管長度僅為1 ~ 1.5m;連接兩個螺旋風管只需要一個連接器，而傳統的矩形風管往往需要一個完全獨立的雙法蘭系統。
1. The installation of spiral air duct greatly reduces the connection points between pipes and reduces the leakage at the connection of pipe fittings. The length of typical spiral air duct is 3 ~ 6m, while the length of typical rectangular air duct is only 1 ~ 1.5m; Connecting two spiral air ducts requires only one connector, while traditional rectangular air ducts often require a completely independent double flange system.
2. 標準化的產品。
2. Standardized products.
螺旋圓管配件(管件、接頭)的生產已高度自動化、系統化，質量控制已工業化。
The production of spiral pipe fittings (pipe fittings, joints) has been highly automated and systematic, and the quality control has been industrialized.
3.較低的安裝成本。
3. Low installation cost.
圓形風管系統的安裝時間僅為類似矩形風管系統的1 / 3。
The installation time of circular duct system is only 1 / 3 of that of similar rectangular duct system.
4. 通常只需要很小的安裝空間。
4. Usually only a small installation space is required.
在相同的安裝空間內，一個200mm直徑的圓管可以代替250mm直徑的管，而不增加任何壓降× 150mm矩形管。在不增加安裝空間的前提下，可以用幾根平行的圓管代替扁的矩形管?？紤]到所有因素，在大多數情況下，圓形管所占用的空間小于矩形管。對于相同的壓力特性，幾根圓形管道的安裝空間往往等于或小于一個矩形管道的安裝空間。很多矩形管道系統在安裝時需要4個螺栓系統，所以在管道的各個方向都增加了40-80mm。
In the same installation space, a 200mm diameter round pipe can replace a 250mm diameter pipe without increasing any pressure drop × 150mm rectangular pipe. On the premise of not increasing the installation space, several parallel circular tubes can be used to replace the flat rectangular tubes. Considering all factors, in most cases, circular tubes occupy less space than rectangular tubes. For the same pressure characteristics, the installation space of several circular pipes is often equal to or less than that of a rectangular pipe. Many rectangular pipe systems require four bolt systems during installation, so 40-80mm is added in all directions of the pipe.
5. 減壓:眾所周知，圓形風管的風阻要比矩形風管的風阻小得多。
5. Decompression: as we all know, the wind resistance of circular air duct is much smaller than that of rectangular air duct.
6. 精密的咬口成型工藝:進口設備使用的模具為特殊鋼結構。即使使用了三、五年，壓模表面保持不變，使鍍鋅鋼板表面不受損壞，風管的使用壽命大大延長。同時接頭均勻，夾緊，連接力強，密封性好。
6. Precise biting forming process: the mold used by imported equipment is of special steel structure. Even if it has been used for three or five years, the die surface remains unchanged, so that the galvanized steel surface is not damaged, and the service life of the air duct is greatly extended. At the same time, the joint is uniform, clamped, with strong connection force and good sealing.
7. 安全密封圈防漏系統。
7. Safety sealing ring leak proof system.
8. 精美的螺旋壓筋工藝，使螺旋風管具有優異的承受壓力的強度。增加螺旋肋后，咬邊縫厚度是管體的4倍，管道的剛性非常大，顯示出堅固性的優點?？沙惺芎艽髩毫d荷而不變形，材料厚度可減少15%，降低成本。
8. The exquisite spiral reinforcement technology makes the spiral air duct have excellent strength to bear pressure. After adding spiral ribs, the thickness of undercut joint is 4 times that of the pipe body, and the rigidity of the pipe is very large, showing the advantage of firmness. It can bear great pressure load without deformation, and the material thickness can be reduced by 15% to reduce the cost.
9. 在相同截面積下，長寬比為1:3的矩形風管周長比螺旋風管長40%;同樣，由于螺旋風管的周長較短，保溫材料也可相應減少。
9. Under the same cross-sectional area, the perimeter of rectangular duct with length width ratio of 1:3 is 40% longer than that of spiral duct; Similarly, due to the short circumference of the spiral duct, the insulation material can be reduced accordingly.
10. 管道布局美觀，立體感強:當管道須作為一種建筑特色暴露出來時，優雅成型的法蘭風管將是合適的選擇。
10. The pipeline layout is beautiful and has a strong three-dimensional sense: when the pipeline must be exposed as an architectural feature, the elegant flange air duct will be the appropriate choice.
The above is a detailed introduction about Shandong ventilation duct, which I hope will be helpful to you If you have any questions, please contact us We will provide you with professional service http://www.fsjt-gov.com
